10A MPPT Solar Battery Charger Waterproof 12V/24V Charge Controller IP68 120W/12V ; 240W/24V

10A MPPT Solar Battery Charger, 12V/24V

Waterproof IP68

Perfectly compatible with 24v panel charge 12v battery, we recommended you do so.

!!! Warnings:
For charging 12v battery, Max solar power is 130W.
24v battery, Max solar power is 260W.

Function
1. Compatible with both 12V and 24V solar system, Auto Switch.
2. MPPT function included, increase solar panel conversion rates.
3. Timer integrated, Can be turned of at 24×7 working.
4. LED display showing the voltage/current/power of the solar panel and load.
5. IP68 Waterproof design. Aluminum case, avoid all kind of corrosion.
6. Single button operation, digital number display, showing voltage, current and power.
7. Battery reverse protect, output short circuit protection, open circuit protection. Still have overcharge, over-discharge, overload protection.
8. TVS lightning protection.

Dimension
LxWxH:104.4*81*28.3mm
mounting size:36*96.4mm
Mounting hole:Φ4.5mm

System Connection Sequence

A. Connect the battery first, the controller will detect the system voltage at start up. 12V battery will show “12”, while 24V battery shows “24”
B.Connect the solar panel, be aware of the correct pole.
C.Connect the DC load
